PVE30 ELEVATOR

Vacuum elevator
The PVE30 Elevator is the smallest home elevator in the world, yet it is just as capable as other residential elevators that are much larger and much more expensive. The PVE30 elevator has a 350lb (159kg) lift capacity and is capable of up to 50 ft. (15m) of rise over as many as five stops. With a 30 inch outside diameter, it is small enough to fit in even the most modest-sized home. If you thought a home elevator was out of reach for you because of size constraints, this is the solution you have been looking for.
The PVE30 Elevator has quickly found its place as the ultimate space-saving solution for those with chronic mobility issues. If you need a home lift system, but do not have the ability to accommodate the PVE52 or even the PVE37 models, the PVE30 is a great option.
This home lift was designed as a compact and cost-effective alternative to taking the stairs, and is ideal for townhouses and other tight areas where a traditional residential elevator wouldn’t even be a consideration. As the smallest of the three vacuum elevator models, it only requires a 32-inch (81.28cm) finished through floor hole for the elevator cylinder (and you!) to pass through. Rather than requiring a large elevator shaft, this self-contained home elevator rests on the existing ground floor and provides a beautiful panoramic view as you travel from floor to floor within your home. During the ascent or descent, you will enjoy cool, ambient temperatures as a cabin fan circulates the air in the cabin and an LED light keeps the cabin lit.
All that is needed to power this mighty elevator is 220V, 25 Amp, single phase service. This is roughly the same as what your washer and dryer use. From an environmental and cost-saving standpoint, the PVE30 draws the least amount of electricity out of all of all home elevator models. Just like the other models in our lineup, it does not even use electricity to descend. Not only will your life be a lot easier now that you can avoid the stairs, but your electric bill will barely change!
Just because it is small doesn’t mean it is any less capable or any less quality-made. It is manufactured from polycarbonate and aluminum, making it one of the best on the market today. Place your confidence in the PVE30 home elevator and you won’t be disappointed.

PVE30 Elevator Standard Features

  • No pit, hoist way, or machine room required
  • 50 ft (15m) Total Rise Max
  • 30 ft/min travelling speed
  • Two to Five Stops
  • External cylinder diameter: 30 inches (750mm)
  • Internal cabin diameter: 20 ½ inches (521mm)
  • Internal cabin height: 6’7” (79 inches/ 2005mm)
  • Entrance way opening: 20 ½ inches (521mm)
  • Weight of unit: 560 lbs for 9’ ceiling
  • Through Floor or Balcony Mount Landings
  • Power Supply: 25 AMP 220VAC
  • In-line door openings
  • Aluminum and polycarbonate cylinder structure
  • Automatic interior LED lighting and fan
  • Mechanical emergency safety brake system
  • One year limited manufacturer warranty
  • ASME A17.7 Certified
Find our technical data below
2 stop PVE30
4 stop PVE30
30 Installation Requirements
30typical4s
TECHNICAL SPECS UB_30
